Small Size (0.6" x 0.6") Intelligent Interactive Synthesizers
Model# Frequency
(MHz) 		(dBc/Hz) Package
@10 kHz @100kHz
1700 - 3400 -85  (Typ.) -108 (Typ.)
4800 - 5400 -83  (Typ.) -103 (Typ.)
4950 - 5500 -82  (Typ.) -103 (Typ.)
 Features
  • Exceptional Phase Noise Performance
  • Standard Programming Interface
  • Ulra Wide Tuning Range
  • Lead Free - RoHS Compliant
  • Patented REL-PRO® Technology
FEATURED PRODUCTS


Miniature Footprint (0.3” x 0.3”)
1 to 7 of 14 Models
Page: 1 2
Note: Specification sheets are in PDF format. Adobe Acrobat Reader ver. 5 or better is required.
Model # Frequency
(MHz)
 Tuning
Voltage
(VDC) 		Typical
Phase Noise
@10 kHz
(dBc/Hz)

Bias Voltage
(VDC)

 Operating
Temp. 		RoHS Compliant
DCO & DXO Series
DCO7075-3 700 to 750 0 to 3 -108 +3 @12 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
DCO80100-5 800 to 1000 0.5 to 8 -111 +5 @26 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
DCO8190-5 810 to 900 0.5 to 16 -118 +5 @34 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
DCO1198-8 1195 to 1205 0.5 to 8 -115 +8 @30 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
DCO200400-5 2000 to 4000 0.5 to 18 -90 +5 @40 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
DCO400800-5
Call Us For More Info. 		4000 to 8000 0.3 to 16 -78 +5 @20 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
DCO432493-5 4325 to 4950 0.5 to 11 -88 +5 @21 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
DCO490517-5 4900 to 5175 0.5 to 5 -88 +5 @22 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
DCO495550-5 4950 to 5500 0.5 to 12 -83 +5 @22 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
DCO608634-5 6080 to 6340 0.5 to 5 -85 +5 @20 mA (Max.) -40 to +85 343
(0.3" x 0.3" x 0.080")
  1 to 7 of 14 Models
Page: 1 2

Exceptional Phase Noise
Miniature Footprint: 0.3” x 0.3” x 0.1”
Excellent Tuning Linearity
Optimized Bandwidth
RoHS Compliant
